What is network detection and response?

Network detection and response (NDR) analyzes network traffic to find suspicious activity and give investigators evidence they can follow: which systems communicated, how activity moved inside the network, and what happened before, and after a detection.

6 min readSources: MITRE ATT&CK, CISA, NIST

If you only read one thing.

NDR is only as useful as the visibility behind it. Check these first.

  1. Coverage

    Which segments and sites can the platform actually see?

  2. Direction

    Internal east-west traffic, internet-facing north-south traffic, or both?

  3. Retention

    Full packets, flows, protocol logs, detections, or only summaries?

  4. Trail

    Can an analyst move from a detection back to the sessions behind it?

01 · How NDR works

How NDR works.

NDR needs visibility into the traffic you care about. That can include north-south traffic entering or leaving the environment and east-west traffic moving between internal systems.

  1. Collect the traffic

    Network evidence can come from taps, SPAN ports, packet brokers, flow records, cloud network telemetry, or imported captures.

  2. Turn it into usable evidence

    Connections become records: source and destination, ports, protocols, timing, DNS activity, session details, data volume, and payload content when available.

  3. Look for suspicious patterns

    Rules, threat intelligence, behavioral analysis, baselines, and correlation can surface activity that deserves investigation.

  4. Give the analyst a trail

    The useful output is the evidence around the activity: systems involved, sessions, sequence, timing, and enough context to investigate what happened next.

Worth knowing

The exact collection method and response capability vary by product. NDR cannot analyze traffic it never receives.

02 · What NDR looks at

What NDR actually looks at.

There is no single NDR data format. The depth of an investigation depends on what the platform can collect and retain. 1 2

Packets and PCAP
Full packet data can preserve protocol headers and, when visible, payload content for deeper forensic review.
Flow and session records
NetFlow, sFlow, and similar records show who communicated, over which ports and protocols, when, and how much data moved.
Protocol metadata
Zeek and similar telemetry turn DNS, HTTP, TLS, SMB, SSH, and other network activity into searchable records.
Network security events
Firewall, IDS/IPS, proxy, and other network controls add detections and context around the traffic being investigated.
Cloud network telemetry
Virtual network flow logs and mirrored traffic extend visibility into cloud workloads where physical taps do not exist.

03 · What it can surface

What network evidence can surface.

NDR is strongest when suspicious behavior leaves a pattern in network communications. These are common examples an analyst may be able to see or investigate.

Lateral movement
A host begins reaching internal systems or services it does not normally use, including new SMB, RDP, SSH, or administrative paths.
Command and control
Repeated outbound connections, unusual destinations, beacon-like timing, or other communication patterns can point to C2 activity.
Reconnaissance and scanning
Bursts of connections across many hosts, ports, or services can reveal internal discovery and network-service scanning.
DNS and protocol abuse
Long or unusual DNS queries, unexpected protocols, uncommon ports, or protocol behavior that breaks the normal pattern can warrant investigation.
Possible data exfiltration
Large or unusual outbound transfers, new destinations, and unexpected transfer methods can provide evidence of data leaving the environment.
Unexpected access paths
New third-party connections, remote access from unusual networks, or communication across a boundary that should be quiet can expose a path worth checking.
Network evidence has limits

Network evidence shows the communication. Host, identity, cloud, or application evidence may still be needed to explain which process or account caused it.

04 · What makes it useful

NDR is only as useful as the visibility behind it.

Before judging any NDR platform, check the collection and investigation path first.

  • Which network segments and sites can the platform actually see?
  • Can it see internal east-west traffic, internet-facing north-south traffic, or both?
  • What is retained: full packets, flows, protocol logs, detections, or only summaries?
  • How much useful context remains when traffic is encrypted?
  • Can an analyst move from a detection back to the sessions and evidence that support it?
  • Who owns the investigation, and which response actions require human approval?
In OT

Collection also has to respect performance, reliability, and safety constraints. Passive network visibility is useful where active probing is inappropriate.

Vulnerability scan vs. OT security assessment

See what your network evidence can tell you.

Talk with our team about how AtlasCyber carries suspicious network activity into an investigated case.

Talk to our team

05 · Where CrunchAtlas fits

Where CrunchAtlas fits.

CrunchAtlas ingests passive network evidence from CrunchSense, existing security tools, PCAP, NetFlow, and Zeek. Suspicious activity is investigated with the supporting evidence attached. Network monitoring stays passive, and consequential production changes remain under operator control.

The same case can continue into forensics, campaign correlation, and incident reporting without starting the investigation over.

06 · FAQ

NDR questions, answered.

What does NDR stand for?

Network detection and response: security technology that analyzes network traffic or network telemetry to detect suspicious activity and support investigation and response.

How is NDR different from IDS or IPS?

IDS and IPS focus on detecting suspicious network activity, and IPS can also block traffic inline. NDR usually adds broader traffic analytics, historical context, investigation workflows, and response capabilities. The exact boundary varies by product.

How do NDR and EDR work together?

They answer different parts of the same investigation. NDR sees network communications. EDR sees activity on the endpoint, such as processes, files, registry changes, and host behavior.

Can NDR still help when traffic is encrypted?

Yes, within limits. Even without payload visibility, metadata such as endpoints, ports, DNS activity, TLS characteristics, timing, session duration, and data volume can support detection and investigation. What is visible depends on the collection method and product.

Can NDR monitor OT networks?

Yes, when the deployment can safely observe the relevant OT segments and protocols. Passive collection monitors communication without actively probing operational devices. Coverage depends on placement, telemetry, protocol support, and operating constraints.

07 · Sources

Sources.

The network traffic, detection, and OT concepts on this page are grounded in MITRE ATT&CK, CISA, and NIST guidance. CrunchAtlas product descriptions are separate from agency guidance.

  1. MITRE ATT&CK, Network Traffic Content (DC0085)
  2. MITRE ATT&CK, Network Traffic Flow (DC0078)
  3. CISA, RITA: Network Traffic Analysis
  4. NIST, SP 800-82 Rev. 3, Guide to Operational Technology (OT) Security

This page is educational. NDR coverage and conclusions depend on network architecture, collection points, telemetry, retention, encryption, integrations, and approved scope.
